What we make

Four systems.
Every opening.

Each system is engineered to disappear into the architecture it serves — precise enough to meet any specification, refined enough to need no apology.

System One

Sliding

Walls of glass that move sideways.

System One is our answer to the large opening — the kind of opening that makes a room feel like part of the landscape. Reach 4.2 metres vertical. Span up to 16 feet in a single continuous run. Glazed with 24mm double-glazed units as standard, with options up to acoustic-laminated specification for urban sites.

Floor-to-ceiling glass walls

Smooth single-finger operation

24mm DGU thermal performance

Wind-load rated

Enquire about Sliding

Specifications

Maximum vertical: 4,200mm

Maximum run: 16ft (4,877mm)

Glazing: 24mm DGU standard; acoustic-laminated available

Thermal break: full-length polyamide bridge

Weather seals: triple-brush pile + EPDM gasket

Hardware: stainless steel rollers, anti-lift block

System Two

Casement

Windows that open all the way.

System Two covers every casement need — from a 5mm single-glazed bathroom light to a 38mm DGU acoustic-laminated master bedroom window. The tilt-and-turn option adds European versatility: tilt for secure ventilation, turn for full access. The slim 70mm frame depth keeps sightlines lean without compromising performance.

Tilt-and-turn versatility

5mm to 38mm glazing range

Multi-point security locking

Slim 70mm profile

Enquire about Casement

Specifications

Glazing range: 5mm single to 38mm DGU

Frame depth: 70mm

Hardware: multi-point espagnolette locking

Tilt-and-turn option available on all sizes

Friction stays: adjustable, concealed

Threshold: low-profile rebated sill

System Three

Grande Entry

The front door, at the right scale.

System Three is built for the entrance that commands attention without shouting. A 65mm sash depth and heavy-duty multipoint locking system support single leaves up to 4 metres. The hinge specification tolerates leaf weights above 200kg. Surface finish options span the full Ventino palette — powder coat, anodised, or wood-laminate foil.

Up to 4m single leaf

5-point multipoint locking

220kg leaf weight capacity

10-year structural warranty

Enquire about Grande Entry

Specifications

Sash depth: 65mm

Maximum single-leaf height: 4,000mm

Maximum leaf weight: 220kg

Locking: 5-point multipoint espagnolette

Hinge: heavy-duty concealed, 3D adjustable

Threshold: rebated low-profile with rain seal

System Four

Slide & Fold

The wall that simply isn't there.

System Four is for the opening that needs to disappear entirely. Panels fold and stack against one or both jambs, leaving a clear unobstructed span. Available in 5mm to 36mm glazing range, multi-panel configurations up to 12 leaves, and corner configurations using a pivoting steel post. The track depth is 32mm — barely a threshold.

Up to 12 panels

Corner configurations

Full clear opening

32mm track depth

Enquire about Slide & Fold

Specifications

Glazing range: 5mm to 36mm

Multi-panel: up to 12 leaves

Corner configuration: pivot steel post

Track depth: 32mm

Hardware: concealed top-hung rollers

Stacking: left, right, or split

A guide

How to choose well.

How wide is the opening?

Spans beyond 3 metres favour System One (Sliding) or System Four (Slide & Fold). Below that, System Two Casement gives you better weather performance.

How tall does it need to be?

System One reaches 4,200mm vertical. System Three Grande Entry goes to 4,000mm. For standard floor-to-ceiling in a typical residence, all four systems work.

What does it face?

North and east elevations need less solar-control glass but more weather sealing. South and west elevations benefit from acoustic DGU and solar-control laminated glass.

Who opens it daily?

Elderly users and children do better with tilt-and-turn casements — single-action, no lifting. Slide & Fold requires two hands. Sliding is the most effortless for large openings.

Performance

Six promises. Every system.

Acoustic

Up to 42dB

Our 38mm DGU acoustic laminated specification reduces external noise by up to 42dB — from the roar of a main road to the quiet of a library.

Weather-tight

600 Pa

Tested to 600 Pascal water pressure. Every frame is sealed with EPDM gaskets and pile seals at all four faces — no water ingress in any Indian monsoon condition.

Dust Seal

Triple seal

Triple-brush pile sealing on all sliding frames. Tested in Delhi winter conditions — the fine dust that defeats standard profiles stays outside.

Wind Load

Zc rated

All systems are rated to Zone C wind loads as per IS 875 Part 3 — covering the highest-wind coastal and hill-station sites in India.

Security

5-point lock

Grande Entry and Casement systems come standard with multi-point espagnolette locking. Anti-lift blocks on all sliding systems.

Longevity

10-year warranty

Ten-year structural warranty on all frame profiles. uPVC profiles are UV-stabilised and impact-modified for Indian climate conditions.

Colour & finish

The finish library.

Three ranges — solid powder coating, wood-effect sublimation transfer, and anodising — across the full Ventino palette. Custom RAL colours available on request for orders above 50 units.

Powder Coating — Solid Colours

RAL 9003

RAL 9010

RAL 9016

RAL 7003

RAL 7032

RAL 7035

RAL 7037

RAL 7039

RAL 7043

RAL 7045

RAL 7022
